HES 9600-12/24D-630 9600 Series Windstorm-Resistant Surface-Mount Electric Strike, 12/24VDC, Satin Stainless Steel

The HES 9600-12/24D-630 (model 9600-630) from the Genesis 9600 series is a surface-mounted, windstorm-resistant electric strike for doors fitted with rim exit devices. It runs on 12 or 24VDC, can be set in the field to fail secure or fail safe, and has a satin stainless steel finish. It suits installers and facility owners who need a tamper-resistant strike with a high rated strength and endurance.

Key features

• Installs in metal or wood frames, though wood screws are not provided.
• The base and decorative cover are separate pieces, which makes adjustments easier.
• Stainless steel construction with a tamper-resistant design.
• Rated for 2,000lb static strength and 120 ft-lb dynamic strength.
• Rated for 1,000,000 cycles of endurance.
• Fail secure or fail safe is selectable in the field, and the unit accepts either 12 or 24VDC.

Specifications

Brand: HES

Model: 9600-630

Product series: 9600

Product type: Electric Strike

Application: Door

Compatible door lock type: Rim Exit

Compatible door frame type: Metal

Door handling: Non-Handed

Security configuration: Fail Secure

Input voltage: 12V DC

Input current: 250mA

Holding strength: 120lb

Material: Stainless Steel

Color: Silver

Height: 1.8″

Width: 0.8″

Features: Horizontal Adjustment

Environmental certification: RoHS

Country of origin: US

Installation notes

Confirm the strike lines up with the rim exit device's latchbolt before final mounting, and use the horizontal adjustment and the separate base and cover to fine-tune the fit. Match the supply voltage to the 12 or 24VDC setting, and set fail secure or fail safe before the door is put into service.
