HES 1006CLB-12/24D-630 1006 Series Complete Electric Strike with J, K, KD and KM Faceplates, Satin Stainless Steel

The HES 1006CLB-12/24D-630 (model 10620443) is a complete 1006 Series electric strike kit for latchbolt locks, supplied with J, K, KD and KM faceplates. It lets you control entry through a door fitted with a cylindrical lock, and it suits installers and businesses that want one strike body to cover several faceplate options. It is fail secure, non-handed, and built from satin stainless steel with an internally mounted solenoid.

Key features

• Fail secure operation is standard, so the door stays locked when power is removed.
• It runs on either 12 or 24VDC continuous duty, which gives you flexibility on the power supply.
• Rated for 2,500lb static strength and 350 ft-lbs dynamic strength in fail secure mode.
• Endurance is rated at 1,000,000 cycles, with tamper-resistant stainless steel construction.
• The non-handed design means one strike works for either door swing.
• It accommodates a deadbolt up to 1″.

Specifications

Brand: HES

Model: 10620443

Product Model: 1006CLB

Product Series: 1006

Product Type: Electric Strike

Application: Door

Compatible Door Lock Type: Cylindrical

Security Configuration: Fail Secure

Door Handling: Non-Handed

Material: Stainless Steel

Color: Silver

Input Voltage: 12V DC

Holding Strength: 2500lb

Height: 4.87″

Width: 1.68″

Depth: 2.06″

Country of Origin: US

Installation notes

Choose the faceplate that matches your door frame and lockset before you cut or mount anything, and confirm the strike aligns with the latchbolt so it releases cleanly. Check that your power supply matches the 12 or 24VDC setting you intend to use, and test the lock several times under power before handing the door over.
