Genesis 55041004 14/1-Pair Solid Unshielded Fire Alarm Cable, NYC Certified, FPLP, 1000' (304.8 m) Reel, Red

The Genesis 55041004 is a 14 AWG, 1-pair solid unshielded fire alarm cable in red, supplied on a 1000' (304.8 m) reel. It is FPLP-rated and NYC certified, and is built for indoor fire alarm wiring where installers need a jacketed solid-copper pair with low voltage drop. Fluoropolymer insulation and jacket and countdown length markings make it a practical pick for fire alarm contractors pulling long runs.

Key features

• Bare copper conductors give good conductivity and keep voltage drop low.
• Fluoropolymer insulation and jacket are used throughout the construction.
• Countdown length markings make it easy to track how much cable has been used and what remains.
• Rated for 300 volts and for temperatures from -20 °C to 150 °C.
• REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 55041004

Product type: Unshielded fire alarm cable

Rating: FPLP, NYC certified

Length and packaging: 1000' (304.8 m) reel

Color: Red

Wire gauge: 14 AWG

Conductors: 2 (1 pair)

Conductor type: Solid

Conductor material: Bare copper

Insulation material: PVDF

Shielding: No

Armored: No

Indoor/Outdoor: Indoor

Voltage rating: 300 V

Temperature rating: -20 °C to 150 °C

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 45.20 lb

Installation notes

Use the countdown markings to plan each run and cut to length with a little slack at the panel and devices. Because this cable is unshielded and rated for indoor use, keep it in suitable indoor pathways and follow local code and the fire alarm panel manufacturer's wiring requirements.
