Genesis 63601106 23/4-Pair Cat 6 Unshielded (U/UTP) Networking Cable, Riser, CMR, 1000' (304.8 m) Pull Box, Blue

The Genesis 63601106 is a 1000' (304.8 m) pull box of blue Cat 6 unshielded (U/UTP) riser-rated (CMR) network cable. It uses 23 AWG solid bare copper conductors in four pairs, making it a fit for installers running indoor Ethernet on larger jobs. Countdown length markings and a rip cord for jacket removal stand out for day-to-day pulling and termination.

Key features

• Bare copper conductors support solid signal transmission with low voltage drop.
• A rip cord lets you strip and remove the jacket efficiently.
• Countdown length markings make it easy to track how much cable you have used and how much remains.
• The PVC jacket is rated sunlight resistant (UV).
• It is rated for 300V and for temperatures from -20 °C to 75 °C.
• The cable is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 63601106

Category: Cat 6

Construction: Unshielded (U/UTP)

Rating: Riser, CMR

Length and packaging: 1000' (304.8 m) pull box

Color: Blue

Number of pairs: 4

Number of conductors: 8

Conductor material: Bare copper

Conductor type: Solid

Wire gauge: 23 AWG

Insulation: PE

Jacket: PVC

Impedance: 100 Ohm

Voltage rating: 300V

Temperature rating: -20 °C to 75 °C

Indoor/Outdoor: Indoor

Shielding: No

Armored: No

Environmental certification: RoHS

TAA compliant: No

Country of origin: VN

Weight: 25.00 lb

Installation notes

Pull the cable gently from the box and avoid sharp bends or excessive pulling tension so the pairs stay intact. This cable is for indoor use, so keep runs inside the building and use the countdown markings to plan lengths before cutting and terminating.
