Genesis 32091012 22/12 Stranded Shielded Cable, Plenum, CMP, FT6, 1000' (304.8 m) Reel, Natural

The Genesis 32091012 is a 22 AWG, 12-conductor stranded shielded cable with a plenum (CMP, FT6) jacket, supplied on a 1000' (304.8 m) reel in natural. It suits indoor security and control wiring where a foil-shielded multi-conductor run is needed, including air-handling spaces. Bare copper conductors and countdown length markings make it easy to work with on longer pulls.

Key features

• Bare copper conductors give good conductivity and keep voltage drop low.
• Low-smoke PVC insulation is used on the conductors.
• A foil shield covers all of the conductors.
• A rip cord helps you strip and remove the jacket cleanly.
• Countdown length markings let you track how much cable you have used and how much is left.
• It is rated for 300 volts and for -20 °C to 75 °C, and it is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 32091012

Product type: Security & Control Cables

Rating: Plenum, CMP, FT6

Length and packaging: 1000' (304.8 m) reel

Color: Natural

American Wire Gauge: 22 AWG

Number of conductors: 12

Solid or stranded: Stranded

Conductor material: Bare copper

Insulation material: LS-PVC

Shielding: Yes

Armored: No

Indoor/Outdoor: Indoor

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 41.50 lb

Installation notes

Use the rip cord to open the jacket instead of cutting into it, so the foil shield and conductors stay undamaged. Terminate the shield according to the connected equipment's instructions, and keep the cable indoors, as it is not listed for outdoor use.
