Genesis 32071112 22/8 Stranded Shielded Cable, Plenum, CMP, FT6, 1000' (304.8 m) Pull Box, Natural

The Genesis 32071112 is a 22 AWG, 8-conductor stranded shielded cable with a plenum (CMP, FT6) jacket, supplied as a 1000' (304.8 m) pull box in natural. It is a security and control cable for indoor low-voltage runs, suited to installers who need a shielded multi-conductor cable for plenum spaces. Bare copper conductors, a foil shield over all conductors and countdown length markings make it practical to pull and track on the job.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Low-smoke PVC insulation covers the conductors.
• A foil shield runs over all conductors.
• A rip cord makes stripping and removing the jacket easier.
• Countdown length markings show how much cable you have used and how much is left.
• Rated for 300 volts and for -20 °C to 75 °C, and REACH/RoHS compliant.

Specifications

Model: 32071112

Brand: Genesis

Product type: Security & Control Cables

Rating: Plenum, CMP, FT6

Length and packaging: 1000' (304.8 m) pull box

Color: Natural

Number of conductors: 8

American wire gauge: 22 AWG

Core/cladding diameter: 22/8

Solid or stranded: Stranded

Conductor material: Bare copper

Insulation material: LS-PVC

Shielding: Yes

Armored: No

Indoor/outdoor: Indoor

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 29.00 lb

Installation notes

Because this is an indoor cable, keep the run inside the building and away from sources of electrical noise where you can. Terminate the foil shield according to the system's grounding requirements, and use the rip cord and length markings to strip the jacket cleanly and keep track of what is left on the box.
