Genesis 45081004 18/6 Solid Unshielded Fire Alarm Cable, Plenum, FPLP, 1000' (304.8 m) Reel, Red

The Genesis 45081004 is an 18 AWG, 6-conductor solid fire alarm cable on a 1000' (304.8 m) reel in red. It is unshielded and plenum-rated (FPLP), so it suits indoor fire alarm system wiring for installers and businesses. Bare copper conductors and countdown length markings stand out for practical day-to-day pulling and tracking.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Low-smoke PVC insulation covers the conductors.
• A rip cord lets you strip and remove the jacket efficiently.
• Countdown length markings make it easy to track how much cable you have used and how much remains.
• It is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 45081004

Product type: Fire Alarm Cable

Gauge: 18 AWG

Conductors: 6

Conductor type: Solid

Conductor material: Bare Copper

Insulation: LS-PVC

Rating: Plenum, FPLP

Shielding: No (unshielded)

Armored: No

Color: Red

Length and packaging: 1000' (304.8 m) reel

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Indoor/Outdoor: Indoor

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 40.20 lb

Installation notes

Use the rip cord to open the jacket cleanly instead of cutting into the conductor insulation, and check the countdown markings to plan runs and avoid short pulls. Because this is solid conductor cable, avoid sharp bends and repeated flexing, and keep it indoors as listed.
