Genesis 41581008 18/6 Stranded Unshielded Fire Alarm Cable, Direct Burial, FPL, CL3, 1000' (304.8 m) Reel, Black

The Genesis 41581008 is an 18 AWG, 6-conductor stranded unshielded fire alarm cable rated FPL and CL3, supplied on a 1000' (304.8 m) reel in black. It is a direct burial, outdoor cable suited to installers running fire alarm circuits between buildings or across a site. Bare copper conductors and a sunlight-resistant jacket stand out, and countdown length markings make it easy to track what is left on the reel.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• SRPVC insulation sits under a PVC jacket.
• A rip cord makes jacket stripping and removal quicker.
• Countdown length markings show how much cable you have used and how much remains.
• Sunlight resistant (UV) rating, with a temperature rating of -20 °C to 75 °C.
• Rated for 300 volts and REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 41581008

Product type: Fire Alarm Cable

Rating: FPL, CL3

Gauge: 18 AWG

Conductors: 6

Conductor material: Bare Copper

Construction: Stranded

Insulation: SR-PVC

Jacket: PVC

Shielding: No

Armored: No

Color: Black

Indoor/Outdoor: Outdoor

Installation type: Direct Burial

Length: 1000' (304.8 m) reel

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 75.10 lb

Installation notes

Because this cable is unshielded and not armored, take care when pulling it through trench or conduit to avoid damaging the jacket. Use the countdown markings to plan each run and cut to length, and keep the cable within its stated temperature range.
