Honeywell HC35WE5R2 35 Series 5MP IR MFZ WDR IP Ball Camera, 2.7-13.5mm Lens, White

The Honeywell HC35WE5R2 is a 5MP wired IP ball camera from the 35 Series, built for indoor or outdoor video surveillance on a network. It pairs a 2.7-13.5mm varifocal lens with 5x optical zoom and infrared night vision, which suits installers who want to set the field of view on site. IP66 and IK10 ratings and NDAA compliance make it a fit for businesses and homeowners who need a weather-resistant, vandal-resistant camera.

Key features

• Records up to 2592 x 1944 resolution for real-time surveillance.
• The varifocal lens and 5x optical zoom let you adjust framing without swapping hardware.
• Infrared illumination reaches up to 164.04' and captures footage at night without external light.
• A CMOS sensor with an f/3.3 maximum aperture supports HD video while using less power.
• Wide dynamic range and 2D noise reduction help with image quality in difficult lighting.
• Runs on 12V DC and supports remote management over an RJ-45 network connection.

Specifications

Brand: Honeywell

Model: HC35WE5R2

Product Series: 35

Product Line: MB Secure

Product Type: Network Camera

Form Factor: Ball

Color: White

Effective Camera Resolution: 5MP

Maximum Video Resolution: 2592 x 1944

Maximum Frame Rate: 30fps

Image Sensor Type: CMOS

Lens Included: Yes

Lens Type: Varifocal

Focal Length: 2.7-13.5mm

Optical Zoom: 5.0x

Maximum Aperture: f/3.3

Field of View (Horizontal): 87.0°

Field of View (Vertical): 63.00°

Shortest Shutter Speed: 1/32000 Second

Longest Shutter Speed: 1/8 Second

Night Vision: Yes

Night Vision Type: NIR Active Illumination

Night Vision Distance: 164.04'

Wide Dynamic Range: Yes

Features: 2D Noise Reduction

Video Formats: MJPEG

Video Signal Format: NTSC

Storage Type: SD Card

Connectivity Technology: Wired

Network (RJ-45): Yes

Remote Management: Yes

Input Voltage: 12V DC

Mount Type: Ceiling Mount

Ingress Protection Rating: IP66

Impact Protection Rating: IK10

Durability: Waterproof

Operating Temperature: -40°F to 140°F

Operating Humidity: 90%

Diameter: 5.00″

Weight: 2.16lb

NDAA Compliant: Yes

RoHS Compliant: Compliant

Environmental Certification: RoHS

Environmentally Friendly: Yes

Country of Origin: VN

Installation notes

Mount the camera on a solid surface and aim it clear of nearby walls or soffits that could reflect infrared light back into the lens at night. Confirm the 12V DC supply and the network cable run before final mounting, then fine-tune the varifocal lens while viewing the live image.
