Genesis 53931106 23/4-Pair Cat 6A Unshielded Riser Networking Cable, Plenum, CMP, FT6, 1000' (304.8 m) Pull Box, Blue

The Genesis 53931106 is a 1000' (304.8 m) pull box of blue, unshielded Cat 6A plenum (CMP, FT6) networking cable with 4 pairs of solid bare copper conductors. It is built for indoor voice and data runs, and suits installers pulling long Category 6A cable runs through plenum spaces. A pair-separator spline, FEP insulation and countdown length markings help with performance and job tracking.

Key features

• Bare copper conductors support strong signal transmission and low voltage drop.
• FEP insulation is used on the conductors.
• A rip cord makes jacket stripping and removal quicker.
• Countdown length markings let you track how much cable you have used and how much remains.
• The cable is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 53931106

Product type: Ethernet cable

Category: Cat 6A

Rating: Plenum, CMP, FT6

Length and packaging: 1000' (304.8 m) pull box

Color: Blue

Pairs: 4

Number of conductors: 8

Conductor material: Bare copper

Conductor type: Solid

Wire gauge: 23 AWG

Insulation material: FEP

Shielding: No (unshielded)

Armored: No

Impedance: 100 Ohm

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Indoor/Outdoor: Indoor

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: TW

Installation notes

Pull the cable gently from the box and avoid sharp bends or kinks so the pair geometry stays intact. Use the countdown markings to plan each run and leave enough slack at both ends for termination and testing.
