Genesis 53931006 23/4-Pair Cat 6A Unshielded Networking Cable, Plenum, CMP, FT6, 1000' (304.8 m) Reel, Blue

The Genesis 53931006 is a 1000-foot reel of blue Cat 6A unshielded twisted-pair cable with plenum (CMP, FT6) jacketing, made for permanent indoor network runs. It carries data at up to 10Gbps over 23 AWG solid bare copper conductors, so it suits installers pulling structured cabling through air-handling spaces. FEP insulation, a rip cord and countdown length markings make it easier to work with on long pulls.

Key features

• Bare copper conductors give good signal transmission and low voltage drop.
• FEP insulation is used on the conductors.
• A built-in rip cord helps you strip and remove the jacket efficiently.
• Countdown length markings make it easy to track how much cable you have used and how much is left.
• The cable is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH and RoHS compliant.

Specifications

Brand: Genesis

Model: 53931006

Category: Cat 6A

Rating: Plenum, CMP, FT6

Length: 1000' (304.8 m) reel

Color: Blue

Shielding: Unshielded

Armored: No

Indoor/Outdoor: Indoor

Number of pairs: 4

Number of conductors: 8

Conductor gauge: 23 AWG

Conductor type: Solid

Conductor material: Bare copper

Insulation material: FEP

Impedance: 100 Ohm

Data transfer rate: 10Gbps

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Environmental certification: RoHS

TAA compliant: No

Country of origin: VN

Weight: 48.10 lb

Installation notes

Pull the cable gently and keep bends wide to avoid damaging the pairs, and avoid kinks and tight cable ties. Use the countdown markings to cut each run to length, and test every terminated link before you close up the ceiling.
