Genesis 45141004 14/4 Solid Unshielded Fire Alarm Cable, Plenum, FPLP, 1000' (304.8 m) Reel, Red

The Genesis 45141004 is a 14/4 solid, unshielded fire alarm cable with a plenum (FPLP) rating, supplied on a 1000' (304.8 m) reel in red. It carries power and signals for fire alarm system wiring, and suits installers and contractors pulling indoor runs. Bare copper conductors, a rip cord for jacket removal and countdown length markings make it easier to work with on the job.

Key features

• Four solid bare copper conductors give good conductivity and low voltage drop.
• Low-smoke PVC insulation is used on the conductors.
• A built-in rip cord lets you strip and remove the jacket efficiently.
• Countdown length markings make it simple to track how much cable you have used and how much is left.
• Rated for 300 volts and for temperatures from -20 °C to 75 °C.
• REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 45141004

Product type: Fire Alarm Cable

Size: 14/4 (14 AWG, 4 conductors)

Conductor type: Solid

Conductor material: Bare Copper

Insulation material: LS-PVC

Shielding: No (unshielded)

Armored: No

Rating: Plenum, FPLP

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Color: Red

Length and packaging: 1000' (304.8 m) reel

Indoor/Outdoor: Indoor

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Weight: 65.20 lb

Installation notes

Use the countdown markings to plan each run and cut only what you need, and use the rip cord to open the jacket cleanly before terminating. Keep the cable within its indoor, plenum-rated use and follow the fire alarm panel manufacturer's wiring guidance and local code for routing and terminations.
