Genesis 21031109 22/4 Solid Unshielded Cable, Riser, CMR, FT4, 1000' (304.8 m) Pull Box, Gray

The Genesis 21031109 is a 22 AWG, 4-conductor solid bare copper security and control cable with a gray PVC jacket, supplied in a 1000' (304.8 m) pull box. It is riser rated (CMR, FT4) and unshielded, so it suits installers running low-voltage wiring for security, controls and audio between floors indoors. Countdown length markings and a rip cord make it easier to measure and strip during longer pulls.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Polypropylene insulation sits under a PVC jacket.
• A built-in rip cord helps you strip and remove the jacket cleanly.
• Countdown length markings let you track how much cable you have used and how much is left.
• Rated for 300 volts and for temperatures from -20 °C to 75 °C.
• Sunlight resistant (UV) rated, and REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 21031109

Product type: Security & Control Cable

Conductors: 4

Gauge: 22 AWG

Conductor material: Bare copper

Construction: Solid

Shielding: No

Armored: No

Insulation: Polypropylene (PP)

Jacket: PVC

Rating: Riser, CMR, FT4

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Indoor/Outdoor: Indoor

Color: Gray

Length and packaging: 1000' (304.8 m) pull box

Weight: 12.20 lb

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Installation notes

Pull the cable from the box without twisting it to avoid kinks, and use the countdown markings to cut runs to length. Because it is unshielded, keep it separated from high-voltage and other noisy wiring where you can.
