Evolution EVSP4K12 Premium 4K HMDI 1x2 Splitter (Replaces 280702)

The Evolution EVSP4K12 is a 1x2 HDMI splitter that sends one source to two displays at the same time. It suits installers and homeowners who need to feed two screens from a single player or receiver. It handles resolutions up to 4K2K at 60Hz with HDR, and it includes EDID management modes to help with compatibility during setup.

Key features

• Sends audio and video from one HDMI source to two HDMI outputs at up to 4K2K (2160p) without loss of quality or resolution.
• Supports 4K2K at 60Hz with 12bit YCBCR 4:4:4 and HDR, plus 3D frame sequential video up to 1080p 60.
• Works with HDCP 2.2 sources and is backwards compatible with older HDCP versions.
• Offers Dynamic and Manual EDID management modes to help with compatibility during installation.
• Passes LPCM 7.1CH, Dolby TrueHD and DTS-HD Master Audio, with 18 Gbps of bandwidth.
• Supports hot-plug and has a status indicator for connection and input HDCP compliance.

Specifications

Brand: Evolution

Model: EVSP4K12

Product type: HDMI Splitter

Product line: Evolution

Number of HDMI inputs: 1

Number of HDMI outputs: 2

Maximum video resolution: 4096 x 2160

VESA mode support: up to QSXGA 2560x2048 60Hz

Bandwidth: 18 Gbps

Input voltage: 5V DC

Color: Black

Width: 4.00″

Height: 7.00″

Depth: 2.30″

Weight: 0.60 lb

Package contents: Evolution Premium 4K HDMI 1x2 Splitter, 5V DC power supply, product manual

Installation notes

Place the splitter close to the source and use the included 5V DC power supply so it has stable power. If a display does not pick up the expected resolution or audio, try the Dynamic or Manual EDID mode and check the status indicator for connection and HDCP compliance.
