Episode ECA-70MIXAMP-1-240D 70V Class D Mixer-Amplifier with Bluetooth, 240W, 1-Channel

The Episode ECA-70MIXAMP-1-240D is a 1-channel Class D mixer-amplifier with Bluetooth that delivers up to 240W. It suits business installs such as stores, where one unit has to mix microphones and background music and drive 70V or low-impedance speakers. It also has a dedicated emergency input for fire alarm or other emergency signals.

Key features

• Class D amplification saves power and keeps the sound clean at high volumes.
• It drives 70V systems as well as 4Ohm to 16Ohm loads, at up to 240W.
• Up to 8 inputs, including Bluetooth, take multiple microphones and analog sources.
• Output options include a balanced line out for daisy-chaining a second amplifier, a fixed record output, and a preamp loop output/amp input for external EQ or DSP.
• Front panel controls cover volume, bass, treble, source selection and individual microphone levels.
• A front panel LED meter shows clipping risk: green is safe and red means clipping is close.

Specifications

Model: ECA-70MIXAMP-1-240D

Brand: Episode

Product Type: Mixer Amplifier

Product Line: MRA

Power Consumption: 300W

Total Harmonic Distortion (THD): 0.1% – 0.5%

Maximum Frequency Response: 16kHz

Operating Temperature: 32-122°F

Dimensions: 16.9″ x 3.75″ x 15.2″

Installation notes

Leave the side vents and rear fan unobstructed, and keep the unit within its operating temperature range. Check speaker wiring and total load against the 70V or low-impedance setup before powering up, then set levels while watching the LED meter so it stays out of the red.
