Genesis 50785506 24/4-Pair Cat 5e Unshielded (U/UTP) Networking Cable, Riser, CMR, 500' (152.4 m) Pull Box, Blue

The Genesis 50785506 is a 500' (152.4 m) pull box of blue Cat 5e unshielded (U/UTP) networking cable, with 24 AWG solid bare copper conductors in 4 pairs. It is a riser-rated (CMR) indoor cable for structured cabling runs, suited to installers and businesses pulling Ethernet through building risers. Countdown length markings and a rip cord make it easier to track usage and strip the jacket.

Key features

• Bare copper conductors support good signal transmission with low voltage drop.
• A rip cord lets you strip and remove the jacket efficiently.
• Countdown length markings show how much cable you have used and how much remains.
• The PVC jacket is sunlight resistant (UV) rated.
• It is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 50785506

Product Name: Cat.5e UTP Network Cable

Category: Cat 5e

Rating: Riser, CMR

Length/Packaging: 500' (152.4 m) Pull Box

Color: Blue

Shielding: No (U/UTP)

Number of Pairs: 4

Number of Conductors: 8

Conductor Material: Bare Copper

Solid or Stranded: Solid

American Wire Gauge: 24AWG

Insulation Material: PE

Jacket: PVC

Impedance: 100Ohm

Voltage Rating: 300 Volts

Temperature Rating: -20 °C to 75 °C

Indoor/Outdoor: Indoor

Armored: No

Environmental Certification: RoHS

TAA Compliant: Yes

Country of Origin: VN

Installation notes

Pull the cable gently from the box to avoid kinks and keep bends easy, and avoid stretching the cable during the pull. Use the countdown markings to plan each run and cut to length with some slack for termination.
