Genesis 47160907 18/8 Solid Unshielded Thermostat Cable, General Purpose, CL2, 250' (76.2 m) Speed Bag, Brown

The Genesis 47160907 is an 18 AWG solid, unshielded thermostat cable with four conductors, supplied as a 250′ (76.2 m) speed bag in brown. It is a general purpose CL2 cable for low-voltage thermostat and control wiring indoors. Bare copper conductors keep voltage drop low, and the sequential length marking makes it easy to track how much cable you have used.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Polypropylene insulation sits under a PVC jacket.
• A rip cord lets you strip and remove the jacket quickly.
• Sequential length marking shows how much cable has been used.
• The cable is rated for 150 volts and for -20 °C to 60 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 47160907

Product type: Thermostat Cable

Gauge: 18 AWG

Conductor count: 4

Conductor type: Solid

Conductor material: Bare Copper

Insulation: Polypropylene (PP)

Jacket: PVC

Shielding: No

Armored: No

Rating: CL2

Voltage rating: 150 V

Temperature rating: -20 °C to 60 °C

Length: 250′ (76.2 m)

Packaging: Speed bag

Color: Brown

Indoor/Outdoor: Indoor

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Installation notes

This cable is for indoor use, so keep runs inside the building and away from sources of damage. Use the rip cord to open the jacket cleanly before terminating, and use the length markings to plan your cut before pulling.
