Genesis 32540111 22/1-Pair Stranded Shielded LonWorks Cable, Plenum, CMP, FT6, 250' (76.2 m) Reel, Pink

The Genesis 32540111 is a 22 AWG, 1-pair stranded shielded LonWorks cable in a pink plenum-rated (CMP, FT6) jacket, supplied on a 250' (76.2 m) reel. It suits installers running control and security cabling through air-handling spaces who want bare copper conductors and FEP insulation. The countdown length markings and rip cord make it easier to track and strip on the job.

Key features

• Bare copper conductors support good signal transmission with low voltage drop.
• FEP insulation covers the conductors.
• A rip cord lets you strip and remove the jacket efficiently.
• Countdown length markings show how much cable you have used and how much is left.
• It is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 32540111

Product Type: Security & Control Cables

Rating: Plenum, CMP, FT6

Length and packaging: 250' (76.2 m) reel

Color: Pink

American Wire Gauge: 22 AWG

Number of Pairs: 1

Number of Conductors: 2

Solid or Stranded: Stranded

Conductor Material: Bare Copper

Insulation Material: FEP

Shielding: Yes

Armored: No

Impedance: 100 Ohm

Environmental Certification: RoHS

TAA Compliant: Yes

Country of Origin: US

Installation notes

Terminate the shield properly at the correct end and keep it continuous through splices, and keep the run away from high-voltage power wiring to limit noise pickup. Use the rip cord to open the jacket cleanly, and follow the bend and pulling guidance for the installation to avoid damaging the cable.
