Genesis 31152105 18/4 Stranded Unshielded Cable, Plenum, CMP, FT6, 1000' (304.8 m) Reel-in-a-Box, Green

The Genesis 31152105 is a 1000' (304.8 m) reel-in-a-box of 18/4 stranded, unshielded control cable in a green plenum-rated (CMP, FT6) jacket. It suits installers running low-voltage control and security wiring indoors, where a plenum rating is needed. Bare copper conductors, a rip cord for easy jacket stripping and countdown length markings make it practical to pull and track on the job.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Low-smoke PVC insulation is used on the conductors.
• A built-in rip cord makes jacket stripping and removal quicker.
• Countdown length markings let you see how much cable you have used and how much is left.
• It is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is REACH/RoHS compliant.

Specifications

Brand: Genesis

Model: 31152105

Product type: Security & Control Cables

Gauge: 18 AWG

Number of conductors: 4

Conductor material: Bare copper

Construction: Stranded

Shielding: No

Armored: No

Insulation material: LS-PVC

Rating: Plenum, CMP, FT6

Voltage rating: 300 V

Temperature rating: -20 °C to 75 °C

Length: 1000' (304.8 m)

Packaging: Reel-in-a-Box

Color: Green

Indoor/Outdoor: Indoor

Environmental certification: RoHS

TAA compliant: Yes

Country of origin: US

Installation notes

This cable is for indoor use only, so keep it out of outdoor and exposed runs. Pull it from the reel-in-a-box to avoid kinks, and follow the bend radius guidance for the cable when routing through plenum spaces.
