Honeywell Home 5800SMOKEV Wireless Smoke and Heat Detector, Round, White (Replaces 5808W3 and 5806W3)

The Honeywell Home 5800SMOKEV is a wireless photoelectric smoke and heat detector with a built-in transmitter, made to give early warning of smoke and fire in VISTA 5800-series systems. It combines smoke, heat, rate-of-rise and low-temperature detection in one round, white, ceiling-mount unit, which suits installers and building owners who want fewer nuisance alarms. A built-in sounder and a monitored smoke chamber that flags when maintenance is due set it apart. It replaces the 5808W3 and 5806W3.

Key features

• Meets the UL 268 7th edition standard.
• A built-in sounder gives clear audible annunciation during potential incidents and low battery conditions.
• Smoothing algorithms and drift compensation help keep nuisance alarms to a minimum.
• A sturdy, versatile mounting base and quick battery pull tabs make it easy to install.
• Highly visible LEDs show power, sensor trouble, alarm and low battery status.
• An accessible test button lets you check the unit's functionality, and the monitored smoke chamber alerts you when maintenance is needed.

Specifications

Brand: Honeywell Home

Model: 5800SMOKEV

Product Line: 5800

Product Series: VISTA

Product Type: Heat Alarm

Sensing Technology: Photoelectric

Detectable Medium: Fire

Application/Usage: Multi-criteria detector with a built-in wireless transmitter capable of detecting smoke, heat, rate-of-rise and low temperature

Connectivity: Wireless

Mount Type: Ceiling Mount

Color: White

Diameter: 4.7″

Depth: 2.3″

Battery Size: CR123A

Battery Chemistry: Lithium (Primary)

Battery Voltage: 3V

Input Voltage: 3V DC

Status Indicators: Yes

UL Listed: Yes

Certifications: ULC S529

Certifications & Standards: CSFM

Country of Origin: IE

Installation notes

Mount the base to the ceiling first, then pull the battery tabs to power the unit and use the test button to confirm it works. Enroll the detector with the panel and check that the wireless signal reaches the receiver from the chosen location before final mounting.
