Honeywell 4232CBM Connected Building Access Control Module

The Honeywell 4232CBM Connected Building Access Control Module is an expansion module that links a compatible control panel to external equipment over a serial connection. It suits installers integrating building systems with third-party hardware, and it mounts inside the panel cabinet and draws its power from the panel's ECP bus. Four status LEDs make troubleshooting straightforward.

Key features

• Mounts directly inside the control panel cabinet with the included double-sided tape.
• Connects to external equipment over a three-wire RS232 or four-wire RS422 interface.
• Four status LEDs help with system troubleshooting.
• Runs on 8-12V supplied from the control panel's ECP bus.
• Draws 50mA nominal and 75mA maximum.
• Requires driver software, which is supplied separately by the third-party vendor you need to work with.

Specifications

Brand: Honeywell

Model: 4232CBM

Product type: Access Control Expansion Module

Application/usage: Building

Device supported: Control Panel

Connectivity technology: Wired

Interface: Three-wire RS232 or four-wire RS422

Input voltage: 8-12V (from control panel's ECP bus)

Current drain: 50mA nominal, 75mA maximum

Features: LED indicator

Dimensions: 3.75″ W x 2.5″ L x 0.875″ D

Environmental certification: RoHS

Packaged quantity: 1

Country of origin: TW

Installation notes

Choose a spot inside the panel cabinet with enough clearance for the module and its serial wiring before pressing the tape into place. Confirm you have the correct driver software from the third-party vendor before commissioning, and use the status LEDs to verify operation once the module is powered from the ECP bus.
