AVYCON AVC-NPE81F180 8MP 4K H.265 Active Detection 180° Panoramic Turret IP Camera with 2.0mm Fixed Lens

The AVYCON AVC-NPE81F180 is an 8MP (3840x2160) IP turret camera that combines a 180° panoramic view with active deterrence. It suits installers and businesses that want one outdoor camera to monitor a wide area and discourage intruders on site. A white light LED, red and blue strobe lights, and a built-in microphone and speaker set it apart from a standard turret.

Key features

• Records at up to 3840x2160 and supports H.265+, H.265, H.264+, H.264 and MJPEG compression.
• Full color and active deterrence modes use a white light LED and a blue and red strobe.
• The built-in microphone and speaker handle audio at the camera.
• 3D DNR, WDR, HLC, BLC and ROI encoding help with image quality, along with intelligent analytics.
• A built-in micro SD card slot accepts cards up to 256GB.
• IP67 ingress protection suits outdoor mounting.

Specifications

Brand: AVYCON

Model: AVC-NPE81F180

Product line: AVC

Product type: Network Camera

Color: White

Effective resolution: 8MP

Maximum video resolution: 3840 x 2160

Maximum frame rate: 20fps

Image sensor: CMOS

Lens: 2.0mm fixed, M12 mount, included

Maximum aperture: f/2.4

Field of view: Diagonal

Shutter speed: 1/5 to 1/20000 second

Minimum illumination: 0.0070lux

Night vision: Yes

Ingress protection: IP67

Durability: Waterproof

Input voltage: 12V DC

Operating temperature: -31°F to 140°F

Operating humidity: 95%

Height: 3.85″

Diameter: 4.59″

Cloud capabilities: Cloud managed

Installation notes

Mount the camera where the strobe and white light have a clear path and where the 180° view covers the area you need. Confirm the 12V DC supply is correct before powering up, and seal any cable entry points to keep the IP67 rating intact.
