Genesis 21075509 22/8 Stranded Unshielded Cable, Riser, CMR, FT4, 500' (152.4 m) Pull Box, Gray

The Genesis 21075509 is a 500' (152.4 m) pull box of 22/8 stranded, unshielded riser-rated (CMR, FT4) cable with a gray jacket. It suits installers running security and control wiring indoors, where eight 22 AWG bare copper conductors are needed in a single jacket. Countdown length markings and a rip cord make it easier to track footage and strip the jacket on the job.

Key features

• Bare copper conductors give good conductivity and low voltage drop.
• Countdown length markings let you see how much cable you have used and how much remains.
• A rip cord helps you strip and remove the jacket efficiently.
• Polypropylene insulation sits under a PVC jacket.
• The cable is rated for 300 volts and for temperatures from -20 °C to 75 °C.
• It is sunlight resistant (UV) rated and REACH/RoHS compliant.

Specifications

Model: 21075509

Brand: Genesis

Product Type: Security & Control Cables

Rating: Riser, CMR, FT4

Length/Packaging: 500' (152.4 m) Pull Box

Color: Gray

American Wire Gauge: 22 AWG

Number of Conductors: 8

Conductor Material: Bare Copper

Solid or Stranded: Stranded

Insulation Material: PP

Jacket: PVC

Shielding: No

Armored: No

Indoor/Outdoor: Indoor

Voltage Rating: 300 V

Temperature Rating: -20 °C to 75 °C

Environmental Certification: RoHS

TAA Compliant: Yes

Country of Origin: US

Installation notes

Because this cable is unshielded, route it away from sources of electrical noise and from mains wiring where possible. Pull from the box without kinking, and use the countdown markings to cut runs to length and keep track of leftover cable.
