Honeywell BDA BDA-PS2-W2 Fiplex Broadband 2-Way Power Splitters, 698-2700 MHz, 50W

The Honeywell BDA-PS2-W2 is a passive 2-way RF power splitter from the Fiplex line, covering 698 MHz to 2.70 GHz. It divides one signal path into two, or combines two paths into one, which suits installers building out distributed antenna or signal distribution systems. Its multistage Wilkinson design keeps insertion loss and VSWR ripple low.

Key features

• Passive design with no power supply required for the splitter itself.
• Built on a multistage Wilkinson configuration.
• Low insertion loss helps preserve signal level through the split.
• Low VSWR ripple across the band.
• Handles 50W as a splitter and 1W as a combiner.
• Models with two, three or four output ports are standard, and other configurations are available on request.

Specifications

Brand: Honeywell

Model: BDA-PS2-W2

Product Line: Fiplex

Product Type: Signal Splitter

Minimum Frequency: 698MHz

Maximum Frequency: 2.70GHz

Power Input (Splitter): 50W

Power Input (Combiner): 1W

Weight: 8.47oz

Environmental Certification: RoHS

Environmentally Friendly: Yes

Country of Origin: CN

Installation notes

Confirm that the splitter's frequency range covers every band in your system, and keep the 1W combiner limit in mind if you use it to merge signals. Use properly terminated connectors and tighten them correctly, and terminate any unused output port so reflections do not affect performance.
