GeoVision GV-AS2120 IP Control Panel, DC 12V

The GeoVision GV-AS2120 IP Control Panel (model 510-AS2120-000) is a door access control panel that manages up to four doors from one unit. It suits installers and businesses that need to combine Wiegand card readers with RS-485 or networked GV-Readers and GV-GF Fingerprint Readers on the same panel. It runs on DC 12V or PoE+ and includes 8 digital inputs and 8 relay outputs built in.

Key features

• Controls four doors in one-way mode, or up to four doors in two-way mode over RS-485 or the network.
• Accepts four Wiegand card readers of 26 to 64 bits.
• Connects up to 8 GV-Readers and GV-GF Fingerprint Readers through RS-485 or the network.
• Has 8 digital inputs and 8 relay outputs built in.
• Fits doors, parking gates and elevator call button access, and supports a tampering alarm.
• Powers from DC 12V, 3A or from PoE+ (IEEE 802.3at, up to 25.5 W).

Specifications

Brand: GeoVision

Model: 510-AS2120-000

Product model: GV-AS2120

Product type: Door Access Control Panel

Application/usage: Door

Identification method: Fingerprint

Number of doors: 4

Number of users: 40000

Wiegand: Yes

Power: DC 12V, 3A / PoE+ (IEEE 802.3at, up to 25.5 W)

Height: 8.0″

Width: 8.3″

Depth: 1.8″

Environmental certification: RoHS

Environmentally friendly: Yes

TAA compliant: Yes

NDAA compliant: Yes

Country of origin: TW

Installation notes

Mount the panel in a secure, accessible location close to the doors it controls, and confirm the reader wiring method (Wiegand or RS-485 / network) for each door before pulling cable. If you power it over PoE+, make sure the switch port can supply the required wattage; otherwise use a properly rated DC 12V supply.
