Eaton Tripp Lite P130-000-AUDIO 4K HDMI Audio Embedder, Extractor with TOSLINK and 3.5mm stereo output, 5.1", HDCP, 4K 30Hz

The Eaton Tripp Lite P130-000-AUDIO is an HDMI audio de-embedder/extractor that pulls the audio out of an HDMI signal so it can feed speakers or an audio system with no HDMI input. It suits setups where a source such as a Blu-ray™ player or video game system needs to connect to separate audio gear. It offers 3.5mm, TOSLINK and RCA outputs and passes 4K UHD video at 30Hz.

Key features

• Separates the audio from HDMI so it can run to a standalone audio system.
• Works with speakers that lack an HDMI input.
• Provides 3.5mm, TOSLINK and RCA audio outputs.
• Supports 2-channel and 5.1 surround sound, with both uncompressed and compressed audio.
• Transmits 4K UHD video at 30Hz and supports 24-bit True Color and 36-bit Deep Color.
• Has an LED indicator for power and signal transmission, and comes with international plug adapters.

Specifications

Brand: Eaton

Model: P130-000-AUDIO

Product Type: Signal Extractor

Application/Usage: Audio De-embedding

Audio Line Out: Yes

HDMI: Yes

VGA: No

Maximum Resolution: 3840 x 2160

Environmentally Friendly: Yes

Packaged Quantity: 1

Country of Origin: VN

Power Supply: External, input 100-240V, 50/60 Hz, 0.3A; output 5V, 1A

Installation notes

Place the unit close to the HDMI source and run the audio output to your speakers or amplifier using the connection that matches their input. Once everything is powered, check the LED indicator to confirm the unit is receiving power and a signal before testing the audio.
