Eaton ELMTSW Wheelock Eluxa Multitone Strobe Horn, FIRE Lettering, Wall Mount, 24V, White

The Eaton ELMTSW is a wall-mount Wheelock Eluxa multitone horn strobe with FIRE lettering, a clear lens and a white housing. It gives indoor fire alarm systems an audible and visual notification device that packs eight alert sounds into one unit, and it meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms. That makes it a practical pick for installers who want one device model to cover several signaling needs.

Key features

• Eight sounds are built into a single device, so one model can cover different signaling requirements.
• It meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms.
• FIRE lettering is printed on the white wall-mount housing.
• A clear lens and LED lamp provide the visual alert.
• It runs on 24V DC and is rated for indoor operation.

Specifications

Brand: Eaton

Model: ELMTSW

Product line: Eluxa Indoor

Product type: Multitone horn strobe

Alarm type: Audible

Application: Emergency

Sound emission: 92dB

Lamp type: LED

Lens color: Clear

Color: White

Input voltage: 24V DC

Power source: DC Power

Connectivity: Wired

Mount type: Wall Mount

Indoor/Outdoor: Indoor

Operating temperature: 32-122°F

Shape: Rectangular

Height: 1.30″

Width: 2.78″

Depth: 4.75″

Weight: 0.33 lb

Compatibility: Compatible with all Fire Alarm Control Panels

Certifications and standards: FCC

Environmental certification: RoHS (compliant)

Country of origin: RO

Packaged quantity: 1

Package contents: Eluxa ELMTSW Horn/Strobe, Mounting Plate

Installation notes

Mount the included plate to a secure wall location indoors, then land the 24V DC wiring and attach the device to the plate. After installation, test each device from the fire alarm control panel and confirm the selected sound and strobe operate as intended.
