Eaton ELMTSR Wheelock Eluxa Multitone Strobe Horn, FIRE Lettering, Wall Mount, 24V, Red

The Eaton ELMTSR is a wall-mount Wheelock Eluxa multitone horn strobe with FIRE lettering, a clear lens and a red housing. It handles audible and visual alarm notification indoors and suits installers and facility teams who want one device that covers several sounder needs. It packs eight alerting sounds into a single unit and meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms.

Key features

• Eight sounds are built into one device, so you can stock a single model for different signaling needs.
• It meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms.
• FIRE lettering is printed on the red wall-mount housing.
• The clear lens works with an LED lamp.
• It runs on 24V DC and is built for indoor use.

Specifications

Brand: Eaton

Model: ELMTSR

Product line: Eluxa Indoor

Product type: Multitone horn strobe

Alarm type: Audible

Application: Emergency

Lamp type: LED

Lens color: Clear

Color: Red

Mount type: Wall mount

Indoor/outdoor: Indoor

Input voltage: 24V DC

Power source: DC power

Connectivity: Wired

Sound emission: 92dB

Operating temperature: 32-122°F

Height: 1.30″

Width: 2.78″

Depth: 4.75″

Weight: 0.33 lb

Shape: Rectangular

Compatibility: Compatible with all Fire Alarm Control Panels

Certifications and standards: FCC

Environmental certification: RoHS

RoHS compliant: Compliant

Country of origin: RO

Packaged quantity: 1

Package contents: Eluxa ELMTSR Horn/Strobe, mounting plate

Installation notes

Fasten the mounting plate to the wall first, then connect the field wiring and attach the device. Confirm the 24V DC supply and polarity at the terminals before powering up, and test the unit with your panel as part of commissioning.
