Eaton ELFHSR Wheelock Eluxa Low Frequency Sounder Strobe, Wall, FIRE Lettering, 24V, 110/177 cd, Indoor, Red

Price: $261.36Model: 110/177
In stock — ready to ship Free US shipping on orders $500+ · $238.64 to go
Need a project quote?
EatonShop all Eaton →
Eaton ELFHSR Wheelock Eluxa Low Frequency Sounder Strobe, Wall, FIRE Lettering, 24V, 110/177 cd, Indoor, Red
  • Free US shipping
    on orders $500+
  • 30-day returns
    unused, in original box
  • Secure checkout
    Shopify Payments
  • Product help
    before & after you buy

About the 110/177

The Eaton ELFHSR is a wall-mount Wheelock Eluxa sounder strobe with red FIRE lettering, built for indoor fire alarm systems. It combines fire and CO low frequency signaling in one device, which suits sleeping rooms where NFPA 72 low frequency sounder requirements apply. Installers will notice its low-profile housing and LED strobe with field-selectable candela settings.

Key features

  • Meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms in a single device.
  • Offers three horn patterns: Continuous, T3, and T3/T4.
  • LED technology keeps current draw low.
  • Low-profile design with a small footprint and a modern look.
  • Candela is field selectable between 110 and 177.

Specifications

Brand: Eaton

Model: ELFHSR

Product line: Eluxa Indoor

Product type: Low frequency sounder and sounder strobe

Alarm type: Audible

Candela settings: 110 / 177

Lettering: FIRE

Color: Red

Lens color: Clear

Lamp type: LED

Input voltage: 33V DC

Power source: DC Power

Connectivity: Wired

Mount type: Wall mount

Application: Indoor

Shape: Rectangular

Durability: UV resistant

Operating temperature: 32-122°F

Height: 6.35″

Width: 4.56″

Depth: 2.63″

Weight: 1.20 lb

Certifications and standards: FCC

Environmental certification: RoHS (compliant)

Package contents: Eluxa ELFHSR sounder/strobe, mounting plate

Packaged quantity: 1

Installation notes

Mount the plate to a secure wall location first, then attach the device and confirm the horn pattern and candela setting match the design before commissioning. Keep the unit within its indoor operating temperature range and test it with the rest of the notification circuit after installation.

Specifications

BrandEaton
Model110/177
Product typeFire Alarm Horn Strobe

Specs are taken from the manufacturer listing. Need a detail that isn't here? Ask us.
