Eaton ELCHSR Wheelock Eluxa Chime Strobe, FIRE Lettering, Ceiling Mount, 24V, Red

The Eaton ELCHSR is a Wheelock Eluxa chime strobe with FIRE lettering and a red housing, built for indoor fire alarm notification. It pairs an audible chime with an LED strobe, and its field-selectable chime modes make it a fit for hospitals and other institutional buildings. The low-current LED design is the standout, helping hold down installation and operating costs.

Key features

• Solid-state chime can be set in the field to 1 Hz, 2 Hz, Coded, or Temporal 3 (T3) operation.
• Power-saving LED technology gives the lowest current draw across the full candela range.
• Lower current draw helps reduce overall installation and operating costs.
• Suited to hospital and institutional applications.
• Compatible with all fire alarm control panels.

Specifications

Brand: Eaton

Model: ELCHSR

Product Line: Eluxa Indoor

Product Type: Chimes and chime strobes

Alarm Type: Audible

Lamp Type: LED

Lens Color: Clear

Color: Red

Input Voltage: 24V DC

Power Source: DC Power

Sound Emission: 78dB

Connectivity: Wired

Mount Type: Wall Mount

Indoor/Outdoor: Indoor

Shape: Rectangular

Width: 2.94″

Height: 6.35″

Depth: 4.56″

Weight: 1.75 lb

Operating Temperature: 32-122°F

Certifications & Standards: FCC

Environmental Certification: RoHS (compliant)

Country of Origin: RO

Packaged Quantity: 1

Package Contents: Eluxa ELCHSR Chime Strobe, Mounting Plate

Installation notes

Set the chime mode before closing up the device, and confirm it matches the project's notification requirements. Wire the unit to a 24V DC notification circuit and keep it indoors within the listed operating temperature range.
