Eaton 31T-115-S Horn, 115VAC, Semi Flush, Silver

The Eaton Wheelock 31T-115-S is a 115VAC fire alarm horn in a silver, semi-flush housing. It sounds an audible alarm for life safety applications where high sound output, low current draw and dependable operation matter. It suits installers and facility owners who want a factory-assembled horn that can be used indoors or outdoors, with a vandal-resistant build.

Key features

• A resonant grille design delivers high sound output while drawing little current.
• It arrives fully assembled from the factory, which saves installation time.
• Screw terminal inputs allow fast, secure in-out field wiring.
• It can be mounted semi-flush or on the surface, indoors or outdoors.
• A textured grey finish gives it a clean appearance.

Specifications

Model: 31T-115-S

Brand: Eaton

Product Line: Eaton Wheelock

Product Series: 31T Horn

Product Type: Horn

Alarm Type: Audible

Sound Emission: 95dB

Input Voltage: 120V AC

Color: Gray

Durability: Vandal Resistant

Indoor/Outdoor: Outdoor

Form Factor: Wall Mount

Mount Type: Ceiling Mount

Shape: Rectangular

Width: 4.00″

Height: 4.00″

Depth: 1.32″

Weight: 1.34 lb

Packaged Quantity: 1

Country of Origin: US

Certifications & Standards: UL, FM

Installation notes

Choose semi-flush or surface mounting to suit the location, and make sure the mounting surface can support the unit. Use the screw terminals for the incoming and outgoing field wiring, and test the horn after installation to confirm it sounds as expected.
