GRI 700-T-W Capped Miniature Surface-Mount Magnetic Switch Set with 3/4-Inch Standard Gap, White

The GRI 700-T-W is a capped miniature surface-mount magnetic contact from George Risk Industries, finished in white. It monitors a sliding window as a normally open Form A contact, and its small size and clean look suit residential jobs and spots where space is tight. It mounts with attached 3M double-sided tape, so there is no drilling into window frames.

Key features

• Its small size makes it a fit for homes and areas with limited space.
• Pre-applied 3M double-sided tape means no drilling into window frames.
• Plated contacts resist sticking or freezing.
• It comes with 12″ #22AWG leads, and longer leads are available on request.
• The 700 series is offered with terminal connection, end leads and center leads.
• Switches and magnets are available separately, and the switch comes in white or brown.

Specifications

Brand: GRI (George Risk Industries)

Model: 700-T-W

Series: 700

Product type: Magnetic contact

Mount type: Surface mount

Gap: 3/4″ standard

Contact form: Form A

Contact type: NO (Normally Open)

Termination style: 2 lead

Lead length: 12″ #22AWG

Connectivity: Wired

Power source: DC power

Input voltage: 160V DC

Input current: 400mA

Power consumption: 10W

Diameter: 0.40″

Length: 12.00″

Width: 1.00″

Color: White

Application: Sliding window

Installation type: Residential

Country of origin: US

Installation notes

Clean and dry the window frame and sash before pressing the tape-backed switch and magnet into place, and keep the magnet within the 3/4″ gap of the switch. Test the loop with the window opened and closed before you run the leads to the panel and finish the cabling.
