Eaton Tripp Lite AVR550U 550VA 300W Line-Interactive UPS 8 NEMA 5-15R Outlets, AVR, 120V, 50/60 Hz, USB, Desktop/Wall Mount

The Eaton Tripp Lite AVR550U is a 550VA/300W line-interactive UPS that gives PCs, workstations and small network gear battery backup, surge protection and voltage regulation. It suits desks and wall-mounted installs alike, and it is also listed for ATM use. Automatic voltage regulation, 316-joule surge protection and eight NEMA 5-15R outlets, four of them battery-backed, make it a compact option for small endpoints.

Key features

• Rated at 550VA/300W for battery backup of small equipment.
• Eight NEMA 5-15R outlets let you power several devices from one unit.
• Automatic Voltage Regulation helps keep output steady when input power varies.
• A 316-joule surge rating and EMI/RFI filtering protect connected gear and help keep power clean.
• HID-compliant USB supports automatic saves and shutdowns.
• Compact, quiet design mounts on a desktop or a wall, with LED indicators for status.

Specifications

Model: AVR550U

Brand: Eaton

Product Series: AVR

Product Type: Line-interactive UPS

Apparent Power Rating: 550.00VA

Power Rating: 300W

Input Voltage: 120V AC

Output Voltage: 120V AC

Input Frequency: 60Hz

Output Frequency: 60Hz

Waveform Type: PWM Sine Wave

Phase: Single Phase

AVR: Yes

Transfer Time: 6ms

Receptacle Detail: 8 x NEMA 5-15R

Number of Battery & Surge Outlets: 4

Number of Surge-only Outlets: 4

Plug/Connector Type: NEMA 5-15P

Surge Energy Rating: 316J

EMI/RFI Noise Filter: Yes

Dataline Protection: RJ-11

Backup/Run Time (Half Load): 9.0min

Backup/Run Time (Full Load): 2.0min

Battery Recharge Time: 8.00hr

Battery Life: 6-Year

Replaceable Battery: Yes

Alarm: Battery Backup

Status Indicators: Yes

Software Included: Yes

Energy Saving: Yes

Form Factor: Tower

Mount Type: Wall Mount

Color: Black

Width: 6.40″

Depth: 12.00″

Height: 4.30″

Weight: 13.69lb

Maximum Operating Temperature: 104°F

Maximum Operating Elevation: 10000'

Environmental Certification: RoHS

Country of Origin: CN

Application/Usage: ATM

Packaged Quantity: 1

Package Contents: AVR550U UPS with 8 outlets, USB cable, owner's manual

Installation notes

Plug the UPS directly into a wall outlet, not a power strip or another UPS. Put critical loads on the battery-backed outlets and use the surge-only outlets for peripherals. If wall mounting, use hardware rated for the unit's weight, and keep it where the vents have airflow and the LED indicators are easy to see.
