Eaton MT4-115-WH-VNS MT Multitone Horn Strobe, Xenon, Wall, No Lettering, Clear Lens, 115 cd, 120V AC, Indoor Outdoor, Gray

The Eaton MT4-115-WH-VNS is a Wheelock MT multitone horn strobe in a gray, wall-mount housing with a clear lens and a xenon lamp. It combines an audible alert and a visual strobe in one fire alarm appliance, so it suits installers and facilities that need both signals from a single device. It offers a choice of eight alerting sounds and flush mounting without an extra trimplate.

Key features

• Flush mounting needs no additional trimplate.
• Eight audible sounds are available, including Horn, Bell, March Time Horn, Code-3 Tone, Code-3 Horn, Slow Whoop, Siren and Hi/Lo.
• The audible and the strobe can run from a single NAC circuit or from separate NAC circuits.
• It is designed to meet or exceed ADA, NFPA, UFC and ANSI standards and accessibility guidelines.
• The xenon strobe has a clear lens.

Specifications

Brand: Eaton

Model: MT4-115-WH-VNS

Product line: Eaton Wheelock

Product type: Multitone horn strobe

Alarm type: Audible

Lamp type: Xenon

Lens color: Clear

Input voltage: 120V AC

Sound emission: 99dB

Mount type: Wall mount

Indoor/Outdoor: Outdoor

Color: Gray

Shape: Rectangular

Width: 4.06″

Height: 4.06″

Depth: 2.20″

Weight: 0.54 lb

Operating temperature: -31 to 150°F

Certifications & standards: FCC

Country of origin: US

Packaged quantity: 1

Installation notes

Decide early whether the horn and strobe will share one NAC circuit or use separate circuits, and run the cabling to match. Select and test the audible sound during commissioning, and mount the unit on the wall where its signal can be heard and seen in the protected area.
