Eaton MB-G10-24-R Motor Bell, Vibrating, Indoor Outdoor, 24VDC, 10" Shell, Red

The Eaton MB-G10-24-R is a vibrating motor bell with a 10″ shell and a red metal finish, built to sound an audible alarm in indoor and outdoor locations. It runs on 24 VDC and is a fit for installers and facility owners who need a loud signal on a fire or alarm system. It offers a high dbA output and, when paired with the GBBB back box, carries an ANSI/UL listing for outdoor use.

Key features

• It delivers a high dbA output for a clearly audible signal.
• It uses four-wire operation and comes with 18 AWG wire leads.
• It mounts to a standard 4″ square electrical box.
• It is ANSI/UL listed for outdoor use when installed with the GBBB back box.
• The red metal finish makes it easy to spot.
• The same bell family is offered in 24 VDC or 120 VAC and in 6″ or 10″ housings.

Specifications

Brand: Eaton

Model: MB-G10-24-R

Voltage: 24 VDC

Shell size: 10″

Finish: Red metal

Wire leads: 18 AWG

Mounting: Standard 4″ square electrical box

Installation notes

For outdoor placement, use the GBBB back box so the installation stays within the listing. Confirm the supply voltage matches the 24 VDC version before connecting the four wire leads, and mount the bell where its sound will carry to the areas it needs to cover.
