Eaton ELCHSWC Wheelock Eluxa Chime Strobe, FIRE Lettering, Ceiling Mount, 24V, White

The Eaton Wheelock Eluxa ELCHSWC is an indoor, ceiling-mount chime strobe with FIRE lettering for 24V DC fire alarm systems. It gives both an audible and a visual signal from one white, circular device, and the chime tone is field selectable between four modes. Its LED strobe technology is built to keep current draw low, and Eaton lists it as suited to hospital and institutional applications.

Key features

• The solid-state chime can be set in the field to 1 Hz, 2 Hz, Coded, or Temporal 3 (T3) operation.
• Power-saving LED technology gives the lowest current draw across the full candela range.
• Lower current draw helps reduce overall installation and operating costs.
• It is intended for hospital and institutional applications.
• The ceiling-mount design is made for indoor building use and comes with a mounting plate.

Specifications

Brand: Eaton

Model: ELCHSWC

Product Line: Eluxa Indoor

Product Type: Chimes and chime strobes

Alarm Type: Audible

Sound Emission: 78dB

Input Voltage: 24V DC

Power Source: DC Power

Lamp Type: LED

Lens Color: Clear

Color: White

Shape: Circular

Mount Type: Ceiling Mount

Indoor/Outdoor: Indoor

Application/Usage: Building

Connectivity Technology: Wired

Compatibility: Compatible with all Fire Alarm Control Panels

Operating Temperature: 32-122°F

Height: 3.64″

Width: 4.60″

Depth: 1.50″

Diameter: 6.20″

Weight: 1.86 lb

Certifications & Standards: FCC

Environmental Certification: RoHS

RoHS Compliant: Compliant

Country of Origin: RO

Packaged Quantity: 1

Package Contents: Eluxa ELCHSWC Chime Strobe, Mounting Plate

Installation notes

Mount the plate to a secure ceiling location first, then make the field wiring connections and attach the device. Set the chime mode to match the system design before commissioning, and test the device with the panel after installation.
