ADI PRO PRO RN-9040501 18/4 Stranded Riser Unshielded Cable, CL3R, 500' Express Box, White

The ADI PRO RN-9040501 is an 18 AWG, 4-conductor stranded riser cable that handles low-voltage security and control wiring. It comes as a 500' Express Box in white, so it suits installers and businesses running unshielded security runs. The bare copper conductors and descending length marking make it easy to measure and pull what you need.

Key features

• Bare copper conductors carry the signal and power on each run.
• The cable is ETL certified and meets all ANSI/TIA/EIA standards.
• Descending length marking lets you see how much cable is left on the spool.
• It is rated CL3R for riser use.
• The white jacket is unshielded and uses stranded conductors.

Specifications

Brand: ADI PRO

Model: RN-9040501

Product Type: Security Cable

Cable Style: Security

Rating: CL3R

Length and Packaging: 500' Express Box

American Wire Gauge: 18AWG

Number of Conductors: 4

Number of Pairs: 2

Solid or Stranded: Stranded

Conductor Material: Copper

Insulation Material: PVC (Polyvinyl Chloride)

Shielding: No

Color: White

Certifications & Standards: ETL

Environmental Certification: RoHS

Installation notes

Keep this unshielded cable routed away from sources of electrical noise where possible, and confirm the CL3R riser rating suits the pathway before you pull it. Use the length markings to plan each run and cut with enough slack for termination.
