Araknis Networks AN-420-SW-F-16-POE 420 Series Managed Layer 2 and Lite Layer 3 Partial Multi-Gig Switch with PoE+, 16-Ports, Front Facing Ports

The Araknis Networks AN-420-SW-F-16-POE is a managed Layer 2 and Lite Layer 3 switch from the 420 Series, with 16 PoE+ ports and partial multi-gig capability. It suits installers and businesses that need a rack-mounted switch to power and manage network devices from one unit, with built-in OvrC support for remote management. The RJ-45 ports face the front, and the cooling fans are designed to run with reduced noise.

Key features

• Works as a managed Layer 2 and Lite Layer 3 switch for more advanced network setups.
• Provides 16 PoE+ ports for powering connected devices over Ethernet.
• Offers partial multi-gig capability on selected ports.
• Includes advanced network management tools.
• Has OvrC support built in.
• Uses efficient cooling fans with reduced fan noise.

Specifications

Model: AN-420-SW-F-16-POE

Brand: Araknis Networks

Product Series: 420

Product Type: Network Switch

Network Switch Type: Managed

Number of Ports: 44

PoE (RJ-45) Port: Yes

Power over Ethernet (PoE): Yes

OvrC Enabled: Yes

Network Management: FW Upgrade: TFTP, HTTP

Power Consumption: 417W

Rack Width: 19″

Rack Depth: 16″

Dimensions: 17.32″ x 1.73″ x 16.14″

Operating Temperature: 32-122°F

Operating Humidity: 10-90%

Certifications: CE

Installation notes

Allow enough rack depth for the switch and the cabling at the front, and leave clearance around the fan vents for airflow. Plan the power supply and PoE load for the connected devices before commissioning, then claim the switch in OvrC for remote management.
