GRI RB-01 Roller Ball Plunger Contact, Closed Loop,A Reed Form, 10W, Brownd

The GRI RB-01-W (RB-01 Plunger Switch) is a white, closed loop roller ball plunger contact from George Risk Industries. It pairs a magnetic reed with a mechanical plunger, so it gives you plunger action in a hermetically sealed switch. It suits doors and windows, where the ball is actuated as the sash slides into its frame, and it also works as a hidden trap device under a protected object.

Key features

• Combines a magnetic reed with a mechanical plunger in a single package.
• The reed is hermetically sealed.
• The ball plunger can be activated from any direction within 360 degrees.
• It responds to the sliding motion of a door or window closing into its frame.
• It can be mounted on a flat surface, such as a display table, as an interior trap device.
• With this use, the protected object sits directly on the switch, which conceals and actuates the roller ball.

Specifications

Brand: GRI (George Risk Industries)

Model: RB-01-W

Product series: RB

Product type: Plunger Switch

Contact type: Closed Loop

Color: White

Mounting: Screw down flange

Contacts: Plated contacts resist sticking or freezing

Installation type: Hybrid (DIY + Professional)

Country of origin: US

Package contents: RB-01 Plunger Switch, Mounting Hardware, Spacers

Installation notes

Mount the switch on a firm, flat surface with the screw down flange, and use the supplied spacers to fine-tune how far the ball sits from the door or window frame. Test the loop after mounting, and confirm the ball is actuated reliably as the door or window closes.
