GRI DS-01T-B Short Roller Ball Plunger Switch, Terminal Block, Closed Loop, with 360˚ of Ball Access and Screw Down Flange, Brown

The GRI DS-01T-B is a short roller ball plunger switch with a closed-loop contact and a terminal block, finished in brown. It is made by George Risk Industries (GRI) and is used to detect when a door or similar surface opens or closes, and it suits both DIY and professional installers. A screw-down flange, 360˚ of ball access and a hermetically sealed body with plated contacts are what set it apart.

Key features

• The terminal block version is marked with a "T" in the model designation.
• Total travel is .200 and pre-travel is .080 ± .030.
• It comes with standard 12″ leads, and longer leads, zip cord or jacketed cable are available on request.
• Built-in E.O.L. resistors and diodes can be ordered on request.
• It is UL and ULC approved.
• The DS-01 series is offered in closed loop and SPDT, and in white or brown.

Specifications

Brand: GRI

Model: DS-01T-B

Product series: DS-01

Product type: Plunger Switch

Color: Brown

Contact type: Closed Loop

Leads: 12″ wire leads

Mounting: Screw down flange

Construction: Hermetically sealed, plated contacts resist sticking and/or freezing

Total travel: .200

Pre-travel: .080 ± .030

Approvals: UL and ULC

Installation type: Hybrid (DIY + Professional)

Country of origin: US

Package contents: DS-01T-B Plunger Switch, mounting hardware, spacer

Installation notes

Fasten the flange securely with the supplied hardware, and set the plunger so the door or surface presses it in fully when closed. Keep the leads clear of moving parts, and test the loop at the panel before closing up the work.
