ICC IC107BP482 48-Port Blank Keystone 2U RMS Patch Panel with 19" Metal Rackmount Housing for Slim Profile Keystone Jacks

The ICC IC107BP482 is a 48-port blank keystone patch panel that mounts in 2U of a 19″ rack. It holds slim-profile keystone jacks for data, voice, audio and video runs, so it suits installers building dense termination points in limited rack space. The flush front face keeps jacks level with the panel, and the 16-gauge steel housing gives it a rigid, durable build.

Key features

• Made from 16-gauge cold-rolled steel with a black powder coat finish for rigidity in rack installations.
• Keystone jacks sit flush with the front face, which reduces cable snags and keeps the panel looking clean.
• Packs 48 ports into two rack units, which helps where space is tight and many connections are needed.
• Accepts slim-profile keystone jacks, including CAT6A, CAT6, CAT5e, HDMI, RCA, USB and F-Type.
• Meets EIA-310-E, is TAA compliant and UL Listed (E125268), and is RoHS certified. Pre-drilled holes fit standard 19-inch racks and cabinets.

Specifications

Brand: ICC

Model: IC107BP482

Product name: High Density Flush Blank Patch Panel

Product type: Blank Patch Panel

Number of ports: 48

Rack units: 2U

Compatible rack width: 19.0″

Form factor / mount type: Rack Mount

Color: Black

Length: 19.00″

Width: 3.50″

Height: 0.50″

Environmental certification: RoHS

TAA compliant: Yes

UL Listed: Yes

Country of origin: TW

Packaged quantity: 1

Package contents: High Density Flush Blank Patch Panel; 4 x #12-24 x 5/8″ pan head, pilot point machine screws; 8 x 6-port high density bezel

Installation notes

Fasten the panel to the rack rails with the supplied screws, using the pre-drilled holes. Populate and terminate the keystone jacks before or after mounting as your cable access allows, and leave enough slack and strain relief so cables are not pulled against the flush face. ICC's Keystone Connector Removal Tool (SKU: ICACSP481, sold separately) can help when removing connectors in a dense panel.
