First Alert VISTAHPKP VISTA H Portrait Keypad

The First Alert VISTAHPKP is a hardwired portrait keypad for VISTA H systems, used to arm, disarm and monitor the panel from the wall. It suits installers adding keypads to a VISTA H Hybrid Series system, and up to 8 hardwired keypads can be on one system. Dedicated Away, Stay and Night quick arm keys and separate Power, Status and Trouble LEDs make everyday operation straightforward.

Key features

• Supports up to 8 hardwired keypads on a single VISTA H system.
• Individual LEDs show Power, Status and Trouble at a glance.
• Dedicated quick arm keys cover Arming Away, Stay and Night.
• The display backlight brightness can be adjusted.
• A piezo-electric sounder provides audible feedback.
• A built-in tamper detects removal from the wall.

Specifications

Model: VISTAHPKP

Brand: First Alert

Product Line: VISTA

Product Series: H

Compatibility: VISTAH Hybrid Series

Power Source: DC Power

Electric Current: 70mA

Width: 3.8″

Height: 6.0″

Depth: 1.2″

Minimum Operating Temperature: 32°F

Installation notes

Mount the keypad on a solid wall surface so the built-in tamper seats properly, and place it where users can reach it easily at the entry or exit. Add the 70mA draw of each keypad to your panel's power budget and use suitable wire for the cable run before adding more keypads.
