HellermannTyton TSR2FW-29-1 Cable Raceway External Corner Cover for 1-1/4-Inch Raceway with 1-Inch Bend Radius, White

The HellermannTyton TSR2FW-29-1 is an external corner cover for 1-1/4″ PVC cable raceway, finished in white. It turns a raceway run around an outside corner while keeping a 1″ bend radius, so installers and facilities teams can route low-voltage cabling neatly along walls. The tamper-resistant cover with a hidden latch stands out, since it protects the cabling yet still opens quickly for maintenance.

Key features

• The cover has a hidden latch that resists tampering and still opens quickly for cable maintenance.
• PVC construction is lightweight and durable, and costs less than metallic raceway systems.
• A flexible hinge is designed to reduce stress cracking and discoloration from repeated opening and closing.
• The fitting keeps a minimum 1″ bend radius to meet TIA/EIA 568-B and 569-A standards.
• The system and fittings come in white, office white and ivory, so they can match a range of décor.

Specifications

Brand: HellermannTyton

Model: TSR2FW-29-1

Product type: Duct Cover

Color: White

Material: PVC

Size: 1″

Raceway size: 1-1/4″

Bend radius: 1″

Packaging: 1 per bag

Country of origin: US

Installation notes

Dry-fit the corner against the adjoining raceway sections before fastening, so the joints line up and the cabling is not forced into a tight bend. Lay the cable in without pulling it taut around the corner, then close the cover and confirm the latch is fully seated.
