Hanwha TNO-X6072EPT1-Z T-Series 2MP Explosion-Proof Bullet Camera, 2.8-9mm Varifocal Lens, Orange/Gray, (Replaces TNO-6070EP-Z)

The Hanwha TNO-X6072EPT1-Z is an explosion-proof bullet network camera from the T-Series, built to watch over hazardous areas where standard cameras cannot be used. It records 1080p video at up to 60 fps through a 2.8-9mm varifocal lens, and it carries Class I/II/III Division 1 and ATEX/IECEx hazardous-location ratings. It suits industrial sites and installers who need NDAA-compliant, PoE-powered coverage in classified zones, and it replaces the TNO-6070EP-Z.

Key features

• Streams 1080p at 60 fps with H.265, H.264 and MJPEG support, plus multiple streaming.
• Wide Dynamic Range of 150dB helps keep detail visible in scenes with strong light and dark areas.
• Built-in gyro-based DIS works to steady the image, and intelligent video analytics and WiseStream II are included.
• Dual micro SD/SDHC/SDXC card slots allow onboard storage.
• Certified for hazardous locations: cFMus Class I, II, III Division 1 Groups B, C, D, E, F, G, along with ATEX and IECEx.
• Powers over PoE.

Specifications

Model: TNO-X6072EPT1-Z

Brand: Hanwha

Product Series: T

Form Factor: Bullet

Color: Orange

Maximum Video Resolution: 1920 x 1080

Maximum Frame Rate: 60fps

Aspect Ratio: 16:9

Image Sensor Type: CMOS

Focal Length: 2.8-9mm

Lens Type: Manual

Lens Mount Type: C-Mount

Iris Type: DC Auto Iris

Field of View: Diagonal

Minimum Illumination: 0.0001lux

Shutter Speed: 1/12000 second to 2 seconds

Night Vision: Yes

Wide Dynamic Range: Yes

Video Formats: H.264

Storage Type: Memory Card

Connectivity Technology: Wired

Network (RJ-45): Yes

Remote Management: Yes

Input Voltage: 12-24V DC

Indoor/Outdoor: Outdoor

Ingress Protection Rating: IP66

Durability: Explosionproof

Operating Temperature: 14°F to 140°F

NDAA Compliant: Yes

Width: 7.20″

Depth: 13.85″

Weight: 14.00 lb

Installation notes

At 14 lb, the camera needs a mount and mounting surface rated for its weight, and cable entries should be sealed in line with the hazardous-location requirements for the site. Set the varifocal lens by hand during commissioning, and confirm the PoE or 12-24V DC supply before final aiming.
