Hanwha SPE-420 5MP 4-Channel HDMI IP Module, RJ-45 10/100 Base-T, (Replaces SPE-110)

The Hanwha SPE-420 is a network video encoder that takes video from four HDMI sources and streams it over IP. It suits installers who need to bring HDMI video into an IP video system, and it supports up to 5MP resolution with H.265, H.264 and MJPEG codecs. It replaces the SPE-110 and connects over a single RJ-45 10/100 Base-T port.

Key features

• Handles resolutions up to 5MP.
• Runs at up to 12 fps at 5MP.
• Supports H.265, H.264 and MJPEG codecs.
• Offers multiple streaming with up to 2 profiles per channel.
• Provides one RJ-45 10/100 Base-T network port.

Specifications

Brand: Hanwha

Model: SPE-420

Product Type: Encoder

Channels: 4

Maximum Resolution: 5MP

Maximum Frame Rate: 12 fps at 5MP

Codecs: H.265, H.264, MJPEG

Video Formats: H.264 / AVC

HDMI: Yes

Network Interface: 1 RJ-45 10/100 Base-T

Form Factor: External

Color: Gray

Depth: 5.03″

Width: 7.01″

Height: 1.34″

Weight: 1.15 lb

Country of Origin: VN

Installation notes

Keep the HDMI cable runs from the sources to the encoder as short as practical, and confirm each source is outputting a supported signal before commissioning. Since it is an external unit, place it where the network cable and HDMI connections are easy to reach and the unit has room for airflow.
