Hanwha QND-6012R1 Q-Series 2MP IR Vandal Dome Camera, 2.8mm Fixed Lens, White

The Hanwha QND-6012R1 is a Q-Series 2MP IR vandal dome network camera in white, made for outdoor video surveillance. It records Full HD at up to 30fps and is powered over PoE. It suits installers and businesses that want a fixed-lens camera with onboard microSD storage, built-in IR night vision and an NDAA-compliant listing.

Key features

• Delivers 2MP (1920 x 1080) video at up to 30fps in all resolutions, using H.265 or H.264, with MJPEG and multiple streams also supported.
• Has built-in IR LEDs with a viewable length of 20m, and it switches to black and white at night.
• Includes motion detection, tampering detection and defocus detection.
• Offers a hallway view (90°/270°) and LDC support, which helps with narrow, tall scenes.
• Records locally to a Micro SD/SDHC/SDXC card, up to 128GB.
• Is a no-audio model with an IP66 rating and a vandal-resistant dome housing.

Specifications

Brand: Hanwha

Model: QND-6012R1

Series: Q

Product type: Vandal Dome Network Camera

Resolution: 2MP (1920 x 1080)

Maximum frame rate: 30fps

Image sensor: CMOS

Lens: 2.8mm fixed

Maximum aperture: f/2

Vertical field of view: 61.50°

Shutter speed: 1/5 second to 1/12000 second

Wide dynamic range: Yes

Video codecs: H.265, H.264, MJPEG

Night vision: Infrared (IR), 20m (65.62′)

Storage: Micro SD/SDHC/SDXC memory card slot, up to 128GB

Network: RJ-45

Power: PoE; 12V DC input

Remote management: Yes

Alarm triggering: Yes

Audio: No audio

Indoor/outdoor: Outdoor

Ingress protection: IP66

Durability: Waterproof

Operating temperature: 14°F to 131°F

Operating humidity: 90%

Color: White

Diameter: 4.30″

Weight: 8.99oz

NDAA compliant: Yes

Country of origin: VN

Installation notes

Run a network cable to the RJ-45 port and power the camera from a PoE switch or injector to keep the cabling simple. Aim the camera away from bright lights and nearby surfaces that could reflect the IR illumination, and check focus and the hallway view setting on site before you finish.
