Hanwha ANO-L6082R A-Series 2MP WDR IR Bullet IP Camera, 3.3-10.3mm Motorized Varifocal Lens, White

The Hanwha ANO-L6082R is a 2MP IR bullet IP camera from the A-Series, built for outdoor and indoor video surveillance where the field of view needs to be adjusted on site. It pairs a 3.3-10.3mm motorized varifocal lens with 120dB WDR and infrared night vision that reaches 30m. An IP66 rating, PoE and a microSD slot make it a practical fit for installers and businesses covering entrances, hallways and perimeters.

Key features

• The motorized varifocal lens with Simple Focus lets you set the view without swapping lenses.
• It records 1920 x 1080 video at 30 FPS at all resolutions using H.265 or H.264, with MJPEG and multiple streams also supported.
• Day and Night (ICR) operation and 120dB WDR help with mixed lighting and low light.
• Built-in analytics cover virtual line crossing, directional detection, enter/exit, tampering and motion detection.
• A microSD/SDHC slot (up to 32GB) allows onboard storage, and the camera is powered over PoE.
• Hallway view and WiseStream II support round out the feature set, and IP66 protection suits outdoor mounting.

Specifications

Brand: Hanwha

Model: ANO-L6082R

Product Series: A

Product Type: Bullet Camera

Effective Camera Resolution: 2MP

Maximum Video Resolution: 1920 x 1080

Aspect Ratio: 16:9

Maximum Frame Rate: 30fps

Image Sensor Type: CMOS

Lens Type: Varifocal

Focal Length: 3.3-10.3mm

Maximum Aperture: f/1.6

Minimum Aperture: f/3.3

Field of View (Vertical): 54.80°

Shortest Shutter Speed: 1/12,000 Second

Longest Shutter Speed: 2 Second

Wide Dynamic Range: Yes (120dB)

Night Vision Type: Infrared (IR)

IR Viewable Length: 30m

Night Vision Distance: 98.43'

Video Formats: H.264

Storage Type: Memory Card

Network (RJ-45): Yes

Remote Management: Yes

Mount Type: Backbox Mount

Ingress Protection Rating: IP66

Durability: Waterproof

Minimum Operating Temperature: -22°F

Maximum Operating Temperature: 131°F

Operating Humidity: 95% RH

Diameter: 3.07″

Weight: 0.86lb

Color: White

NDAA Compliant: Yes

Country of Origin: VN

Installation notes

Run a network cable to the mounting point and power the camera from a PoE switch or injector to avoid a separate power run. Aim the camera and adjust the motorized zoom and focus during commissioning, and keep the IR path clear of nearby walls or soffits to limit reflections at night.
