Episode ES-HTR-ICLCR-4 Home Theater Reference Series In-Ceiling LCR Speaker, 4"

The Episode ES-HTR-ICLCR-4 is a 4″ in-ceiling LCR speaker from the Reference series of Episode's Home Theater line. It is built to handle the front left, center and right channels in a home theater, and suits installers and homeowners who want a ceiling-mounted option for immersive audio. A 2″ aluminum dome midrange and carbon fiber woofers stand out, along with Linkwitz-Riley filters and tonal balance controls.

Key features

• The 2″ aluminum dome midrange is designed to deliver detailed audio.
• Carbon fiber woofers resist deformation.
• Linkwitz-Riley filters support better dynamic range.
• Tonal balance controls let you optimize the sound.
• The speaker is acoustically matched for an immersive experience.
• It follows Episode's Sound Based on Science approach as a reference level offering.

Specifications

Brand: Episode

Model: ES-HTR-ICLCR-4

Product Line: Home Theater

Product Series: Reference

Product Type: In-ceiling

Maximum Frequency Response: 25kHz

Sensitivity: 89dB

Impedance: 6Ohm

Dimensions: 15.35″ x 15.35″ x 6.65″

Cutout Dimensions: 14.33″ x 14.33″

Installation notes

Check the ceiling cavity for joists, ductwork and wiring before cutting, and confirm the available depth against the speaker's listed dimensions. Match the amplifier to the listed impedance, and use the tonal balance controls to fine-tune the sound once the speaker is in place.
