ELK ELK-M1KP LCD Keypad for M1 Controls, Blue LCD Display

The ELK ELK-M1KP (model ELKM1KP) is an addressable LCD keypad built for ELK M1 Cross Platform Controls. It handles day-to-day arming, status and menu navigation, and suits installers and system owners who want a readable display on an M1 system. The blue LCD uses large characters and an adjustable backlight, and the keypad can take an optional plug-in proximity card reader.

Key features

• Large characters on the back lighted display are easy to read, and the backlight intensity is adjustable.
• Dedicated navigation and direction keys are provided for moving through menus, along with Exit, Stay, Chime and Bypass keys.
• It connects over four wires on the M1 data bus.
• The built-in speaker has an adjustable beep tone and volume.
• It includes an input for one supervised zone and one programmable voltage output.
• A removable hinged door covers the keys.

Specifications

Brand: ELK

Model: ELKM1KP

Product Model: M1KP

Product Type: Security Keypad

Product Line: M1

Device Supported: Alarm System

Display: Blue LCD

Color: White

Application/Usage: Commercial

Installation Type: Residential

Indoor/Outdoor: Indoor

Mount Type: Surface Mount

Form Factor: Surface Mount

Width: 6.90″

Height: 5.30″

Depth: 1.40″

Environmental Certification: RoHS

Country of Origin: US

Installation notes

Mount it indoors on a surface at a comfortable viewing height, and run the four-wire M1 data bus cable back to the control before powering up. If you plan to use the optional proximity reader, the supervised zone input or the voltage output, plan those connections and programming during commissioning.
