D-Link DGS-1100-08PV2 8-Port Gigabit PoE Smart Managed Switch

The D-Link DGS-1100-08PV2 is an 8-port Gigabit PoE smart managed switch that powers and connects PoE devices over twisted pair. It suits small to enterprise networks, and D-Link positions the DGS-1100 Series as a fit for IP surveillance deployments. It has a 64W PoE budget, a fanless design and a web interface for management.

Key features

• Eight Gigabit PoE ports support IEEE 802.3at, with up to 30W available on any single port.
• A 64W total PoE budget is shared across the powered ports.
• The fanless design runs silently.
• The compact desktop form factor makes placement easy.
• A full web interface handles switch management.
• D-Link Green energy-saving features are included.

Specifications

Brand: D-Link

Model: DGS-1100-08PV2

Product Series: DGS-1100

Product Line: Smart Switch

Product Type: Ethernet Switch

Network Switch Type: Managed

Layer Supported: 2

Ethernet Technology: Gigabit Ethernet

Network Technology: 1000Base-T

Media Type Supported: Twisted Pair

Total Number of Network Ports: 8

PoE (RJ-45) Port: Yes

PoE Budget: 64W

Power Source: PoE (Power over Ethernet)

Power Consumption: 77.9W

Mount Type: Desktop Mount

Color: Green

Width: 6.70″

Depth: 3.90″

Height: 1.10″

Weight: 15.17 oz

TAA Compliant: Yes

NDAA Compliant: Yes

Country of Origin: TW

Packaged Quantity: 1

Installation notes

Add up the power draw of the connected PoE devices and confirm the total stays within the switch's PoE budget before you commission it. Place the switch on a stable, ventilated surface and keep cable runs on twisted pair within standard Ethernet distance limits.
